Catalogue

Pump control cabinets

Pumping station automation and control

from 28,000 ₽

13 models in the catalogue

Request a commercial proposal

In every range

Dispatching: SIGMACS Cloud, Modbus TCP/IP, Modbus RTU, GSM
Bypass: via contactor / via soft starter
Cabinet heating with thermostat
Two power inputs: manual changeover / automatic transfer switch
Weintek 4"/7"/10" operator panel or equivalent
Protection: short circuit, overload, phase loss/imbalance, dry running, overheating

Filter by parameters

Pumps

Starting

Power

Ingress protection

Basic range

Direct-on-line start and soft starter

5 models

SIGM-SHUN-PP-0.75
Power
0.75 kW
Pumps
1
Starting
Direct
Voltage
3×380 V
from 28,000 ₽
SIGM-SHUN-PP-5.5
Power
5.5 kW
Pumps
1
Starting
Direct
Voltage
3×380 V
from 36,900 ₽
SIGM-SHUN-PP-22
Power
22 kW
Pumps
1
Starting
Direct
Voltage
3×380 V
from 48,500 ₽
SIGM-SHUN-UPP-45
Power
45 kW
Pumps
1
Starting
Soft starter
Voltage
3×380 V
from 72,000 ₽
SIGM-SHUN-PP-90
Power
90 kW
Pumps
1
Starting
Direct
Voltage
3×380 V
from 95,000 ₽

Compare specifications in a table

Model	Power	Pumps	Starting	Voltage	IP	Dimensions, mm	Price
SIGM-SHUN-PP-0.75	0.75 kW	1	Direct	3×380 V	54	400×300×200	from 28,000 ₽
SIGM-SHUN-PP-5.5	5.5 kW	1	Direct	3×380 V	54	500×400×220	from 36,900 ₽
SIGM-SHUN-PP-22	22 kW	1	Direct	3×380 V	54	600×500×250	from 48,500 ₽
SIGM-SHUN-UPP-45	45 kW	1	Soft starter	3×380 V	31	800×600×300	from 72,000 ₽
SIGM-SHUN-PP-90	90 kW	1	Direct	3×380 V	31	1200×750×300	from 95,000 ₽

Variable frequency control

Cascade pump control

6 models

SIGM-SHUN-CHRP-0.75-2
VFD power
0.75 kW
Pumps
2 (1+1)
Voltage
3×380 V
IP
54
from 145,000 ₽
SIGM-SHUN-CHRP-2.2-2
VFD power
2.2 kW
Pumps
2 (1+1)
Voltage
3×380 V
IP
54
from 158,000 ₽
SIGM-SHUN-CHRP-5.5-2
VFD power
5.5 kW
Pumps
2 (1+1)
Voltage
3×380 V
IP
54
from 185,000 ₽
SIGM-SHUN-CHRP-15-3
VFD power
15 kW
Pumps
3 (cascade)
Voltage
3×380 V
IP
54
from 340,000 ₽
SIGM-SHUN-CHRP-37-3
VFD power
37 kW
Pumps
3 (cascade)
Voltage
3×380 V
IP
54
on request
SIGM-SHUN-CHRP-75-3
VFD power
75 kW
Pumps
3 (cascade)
Voltage
3×380 V
IP
54
on request

Compare specifications in a table

Model	VFD power	Pumps	Voltage	IP	Features	Price
SIGM-SHUN-CHRP-0.75-2	0.75 kW	2 (1+1)	3×380 V	54	Cascade, variable master	from 145,000 ₽
SIGM-SHUN-CHRP-2.2-2	2.2 kW	2 (1+1)	3×380 V	54	Bypass, dispatching, operator panel	from 158,000 ₽
SIGM-SHUN-CHRP-5.5-2	5.5 kW	2 (1+1)	3×380 V	54	Modbus support	from 185,000 ₽
SIGM-SHUN-CHRP-15-3	15 kW	3 (cascade)	3×380 V	54	Process control, alternation	from 340,000 ₽
SIGM-SHUN-CHRP-37-3	37 kW	3 (cascade)	3×380 V	54	Industrial design	on request
SIGM-SHUN-CHRP-75-3	75 kW	3 (cascade)	3×380 V	54	Maximum power of the series	on request

Sewage pumping stations

Specialised solutions for sewage pumping stations

2 models

SIGM-KNS-2N-11
Purpose
Sewage station, 2 pumps
Power
11 kW
Features
Dry-running protection, level control
on request
Request a quote
SIGM-KNS-3N-22
Purpose
Sewage station, 3 pumps
Power
22 kW
Features
Redundancy, emergency alarms
on request
Request a quote

Compare specifications in a table

Model	Purpose	Power	Features	Price	Request
SIGM-KNS-2N-11	Sewage station, 2 pumps	11 kW	Dry-running protection, level control	on request	Request a quote
SIGM-KNS-3N-22	Sewage station, 3 pumps	22 kW	Redundancy, emergency alarms	on request	Request a quote

Prices are indicative and depend on configuration, deadlines and batch size. The exact cost is given once the task is clarified.

Can't find the right cabinet?

Most cabinets are built to the client's documentation. Fill in the questionnaire and attach your design or specification — we will calculate a cabinet for your task.

Fill in the questionnaire

Automation

Pumping station automation

Up to six pumps, rotation, protections and AutoStop

How it works

Consultation

Get a free consultation

We will call you back shortly and help with project calculation, cost estimate and equipment selection.

Email for requests: info@sigmacs.pro
Specification: Attach a file to the form or send it by email — PDF, Word, Excel, DWG.
